New press brake for sale machine supply for tooling

HG Series has the most advantage in thick or long plate. It brings best quality, simple operation and an attractive price-performance ratio. This means you can save the cost to make more profit within precise results as well as the highest safety standards.

New press brake for sale machine supply for tooling-2

New press brake for sale machine supply for tooling-3

Show details

New press brake for sale machine supply for tooling-4

New press brake for sale machine supply for tooling-5

Operation Mode

Model		Unit	AG-3200
Bending Length		mm	3200
Plate Length		mm	3200
Plate Width		mm	3200
Bending Height		mm	175/350
Min Forming Size (Four sides)		mm	200*400
Min Forming Size (Two sides)		mm	150
Min Radius		mm	1.2
Bending Speed		s	0.5
Opening Height		mm	200/ 400
Angle		/	0-360°
Pressure		kN	800
Material Thickness		mm	3
Numerical System		/	Japan NADIC
Operating System		OS	Win7+OS
Axis		axes	9/11
Machine Dimension	Length	mm	3800
	Width	mm	4450
	Height	mm	2600
Machine Weight		kg	11000

Part Name	Country	Manufacturer	Remarks
Rack	China	Ragos
Mold clamping	China	Ragos
Control system	Japan	Developed with NADIC co., LTD
Servo motor	Japan	SANYO
Servo	Japan	SANYO
Guide rail	Taiwan	HIWIN
Ball screw	Taiwan	TBI
Miniature relay	France	Schneider
Ac contactor	France	Schneider
Button	France	Schneider
Electrical components	France	Schneider
Reducer	Taiwan	APEX

l******y

Ragos press brake for sale is designed to meet specific heavy-duty requirements. Its design features mechanical structure enhancement, low energy consumption, and durable components. Using high quality cables, the product features great conductivity

l******i

The manufacture of Ragos press brake for sale includes three major stages, namely, rough machining, semi-finish machining, and finish machining. All of these stages are carried out by professional mechanical technicians. The product can withstand a wide range of operating temperature from -29ºC to +45.5ºC

o******g

Material is also a key factor in determining the final machine performance of Ragos press brake for sale. Therefore, all of the materials and components have to be tested for mechanical properties. The product can withstand a wide range of operating temperature from -29ºC to +45.5ºC

j******h

The manufacture of Ragos press brake for sale covers several important stages. They mainly include the preparation of raw materials, parts machining, plating and anodizing, assembly, and testing. The product can effectively output fixed voltage

q******p

Ragos press brake for sale has been tested in terms of many aspects. They mainly include mechanical structure, the performance of components, and statics&dynamics effect. Featuring automatic thermal cut-off function, the product will not accumulate too much heat

r******d

This product is internationally renowned for its superior performance and long life. The built-in cooling fan protects this product form overheat
